Installation Guides
Comprehensive technical instructions and guidance for the proper installation of your Daud Dynamic architectural fixtures.
Baths
Installation Instructions
1. Turn off water supply.
2. Position the bathtub on the pre-leveled floor.
3. Connect the drain assembly to the waste pipe.
4. Connect water supply lines.
5. Turn water back on and check for leaks.
6. Apply silicone sealant around base if required.
Installation Instructions
1. Position the tub on level flooring and adjust claw feet levelers.
2. Connect the freestanding tub filler supply lines.
3. Attach the drain and overflow assembly.
4. Test all connections for leaks before use.
Installation Instructions
1. Prepare the tub deck opening per dimensions.
2. Lower the tub into the deck cutout.
3. Apply plumber's putty under the rim flange.
4. Connect the drain and overflow assembly.
5. Secure the apron if applicable.
6. Caulk around the rim with silicone.
Installation Instructions
1. Fit the ledger board at required height.
2. Slide tub into alcove and level with adjustable feet.
3. Secure the tub flange to wall studs.
4. Connect drain and overflow.
5. Tile and caulk around the surround.
Installation Instructions
1. Ensure floor load capacity exceeds 900 lbs.
2. Position bath and connect freestanding floor-mounted tap.
3. Install drain assembly and waste connection.
4. Seal stone surface annually with approved stone sealer.
Showers
Installation Instructions
1. Mark stud positions on the wall.
2. Install mounting bracket into studs.
3. Connect hot/cold water supplies to the tower inlets.
4. Hang the tower onto the bracket.
5. Test all jets and adjust pressure.
Installation Instructions
1. Install wall channels plumb on both walls.
2. Set the glass door into the pivot hinges.
3. Attach the fixed glass panel to the wall channel.
4. Install the door sweep and magnetic closure.
5. Apply silicone bead to all seams.
Installation Instructions
1. Locate ceiling joists.
2. Cut opening and install blocking between joists.
3. Run supply pipe to ceiling position.
4. Fit concealed arm and connect showerhead.
5. Patch ceiling, tile, and seal.
Installation Instructions
1. Turn off main water supply.
2. Install thermostatic valve body in wall cavity.
3. Connect hot and cold inlets.
4. Fit overhead arm and rainhead.
5. Connect hand shower slide rail.
6. Restore supply and calibrate temperature stop.
Installation Instructions
1. Install generator in a dry accessible location max 25ft from steam head.
2. Connect to dedicated 240V circuit.
3. Plumb cold water supply to inlet.
4. Connect condensate drain.
5. Install steam head at knee level in shower.
Faucets
Installation Instructions
1. Install escutcheon plate on single-hole sink.
2. Insert faucet through hole and secure with mounting nut.
3. Connect supply hoses to hot and cold.
4. Turn on supply and check flow.
Installation Instructions
1. Fix the valve body to wall with concealed fixings.
2. Connect hot and cold in-line supplies.
3. Connect the outlet ports to overhead and handheld feeds.
4. Set temperature limit stop to max 43°C.
Installation Instructions
1. Turn off supply valves under sink.
2. Feed lines through sink hole.
3. Secure base with mounting nut.
4. Connect hot/cold supply lines.
5. Turn water back on slowly.
6. Test handle operation.
Installation Instructions
1. Close supply valves.2. Insert each tap into basin holes.3. Secure with back nuts.4. Connect supply tails to isolation valves.5. Open valves slowly and check for drips.
Installation Instructions
1. Mark the position on the countertop.
2. Drill a 35mm hole.
3. Insert the faucet body and secure with the mounting nut.
4. Connect the flexible supply hoses.
5. Attach the pop-up waste assembly.
Vanities
Installation Instructions
1. Locate wall studs and mark fixing positions.
2. Install the wall bracket firmly into studs.
3. Hang the vanity unit on the bracket.
4. Connect the under-mount basin drain.
5. Connect supply lines to mixer faucet.
6. Seal all edges with silicone.
Installation Instructions
1. Mark recess area between studs.
2. Cut drywall and frame the opening.
3. Run electrical to shaver socket.
4. Fit the cabinet into recess.
5. Secure with screws through internal fixing points.
6. Connect LED wiring.
Installation Instructions
1. Apply construction adhesive to the vanity top.
2. Lower basin onto surface and align.
3. Press firmly and wipe away excess adhesive.
4. Connect drain assembly.
5. Seal the basin edge with waterproof silicone.
Installation Instructions
1. Position the vanity and level with adjustable feet.
2. Secure to wall through the back panel.
3. Connect both drain assemblies to waste pipes.
4. Connect supply lines to both faucets.
5. Caulk along the wall.
Installation Instructions
1. Fit the basin bracket to the wall at required height.
2. Seat the basin onto the bracket.
3. Connect the drain.
4. Install the deck-mounted faucet on the shelf ledge.
5. Seal the basin-to-wall joint.
Hardware
Installation Instructions
1. Mark position at 65"–70" height.
2. Drill two pilot holes per hook.
3. Insert anchors.
4. Align hook base plate and screw in.
5. Snap cover cap over screws.
Installation Instructions
1. For hardwired: route cable through wall to junction box.
2. Mount top and bottom brackets plumb.
3. Hang ladder onto brackets.
4. Connect wiring to thermostat switch.
5. For plug-in: mount and connect to switched outlet.
Installation Instructions
1. Mark wall at desired height using level.
2. Drill pilot holes.
3. Insert wall anchors.
4. Secure mounting brackets.
5. Snap rail onto brackets.
6. Check rail is level.
Installation Instructions
1. Mark positions for both pieces.
2. Drill pilot holes.
3. Secure mounting plates with screws.
4. Clip dispenser and dish onto plates.
5. Fill dispenser with liquid soap.
Installation Instructions
1. Mark the fixing holes at standard 26" height.
2. Drill and insert wall anchors.
3. Screw the back plate to the wall.
4. Slide the square bar into the side flanges.
5. Insert spring-loaded holder bar.
